Product Features
- Designed for unlimited fatigue life based on the specified torque requirements.
- The housing is made of high-load-capacity ductile iron, with spur gear meshing between the sun gear and planetary gears.
- Gears and bevel gears are processed with profile modification and gear grinding technology, followed by hardening treatment. The internal gear ring is treated with high-temperature quenching and tempering.
- Compact and space-saving design eliminates the need for additional couplings and adapter flanges.
- Modular input and output design makes it easy to combine with or replace other gear reducers.
Product Parameters
| Output Torque: | 2,500 – 18,000 Nm |
| Gear Ratio: | 3.43 – 3171 |
